Here we take the Client Router (WISP) mode for example. If you want to
achieve other applications, please refer to the User Guide on the resource
CD.
1
2
3
Connect your computer to the LAN port of your Router with an
Ethernet Cable.
Plug one end of the provided power adapter into the POWER jack
of the Router, and the other end to a standard electrical wall socket.
Then press the ON/OFF button of the Router.
Please conrm the work mode switch is in WISP mode.
Note
1. You are recommended to place the Router away from
electrical devices, such as ceiling fans, home security
systems, microwave and the base for a cordless phone.
2. If the distance between the outlet and the Router is too long
to supply power, you can set up the hardware connection
with the provided Passive PoE Injector.
Hardware Connection
1
WISP Signal
SOCKET
TL-WR843ND
Notebook
To Next Page
