TP Forest Single Swing TP303 - Page 10

TP304 Forest Double Swing
M8 x 140mm x2
FA9775
M8 x 140mm
M8
B
M6 x 70mm x4
FA5170
3
TP303 Forest Single Swing
M8
M8
M6
M6
M6 x 70mm
MW1226 x2
MW1235 x4
M6
FA5192
x4
M6 x 20mm
FA5094
x4
M8 x 25mm
FA7184
x4
M8
FA5174
x2
A
TP303 MW1232
TP304 MW1236
10
Forest Single and Double Swing
TP303 TP304 Double Swing - Flag Hole IN1903A Issue-H 21.02.20 A5 Print.indd 10 15/10/2020 16:15
