TP304 Forest Double Swing
M8 x 30mm x4
FA5124
M8 x 30mm
M8 x 30mm
M8 x 25mm
FA7184
x4
4
TP303 Forest Single
Swing
PM1007
x1
3mm ø
11
Forest Single and Double Swing
TP303 TP304 Double Swing - Flag Hole IN1903A Issue-H 21.02.20 A5 Print.indd 11 15/10/2020 16:15
