TPI 100 - Maintenance

54
Function Range Resolution Accuracy
DCV 1.5V- 4V 0.001V
40.00V 0.01V ±(0.5% + 4)
400.0V 0.1V
600V 0.1V ±(0.8% + 4)
ACV 1.7V-4V 0.001V
40.00V 0.01V ±(0.8% + 4)
400.0V 0.1V
600V 1V ±(1.2% + 4)
OHM 400.0 0.1
4.000k 0.001k
40.00k 0.01k ±(0.8% + 4)
400.0k 0.1k
4.000M 0.001M
40.00M 0.01M ±(2.0% + 4)
GENERAL SPECIFICATIONS
Power Supply 2 Each 1.5 Volt “AA” Batteries
Battery Life 560 hrs. Alkaline
Size (H x L x W) 45mm x 78mm x 153mm
(1.8” x 3.1” x 6.0”)
Weight 340g (12 oz)
MEASURING AC/DC VOLTAGE
Make sure that the ground and positive leads
are plugged into the proper receptacle for cor-
responding function positions.
Do not attempt to make a
voltage measurement of
more than 500V or of a
voltage that is unknown.
Measurement Procedure:
1. Disconnect power to circuit to be
measured.
2. Plug black test lead into the COM input jack.
3. Plug the red test lead into the V/
W
input
jack.
4. Set the rotary switch to the “ON” position.
5. Connect test leads to circuit to be mea-
sured.
6. Reconnect power to circuit to be mea-
sured.
7. Read the voltage on the TPI 100.
Note: For Auto mode to operate
properly, DC voltage must be between
+0.7 and 600V. AC voltage must be
between 3 and 500V.
SPECIFICATIONS
