TPS 901-PH - pH Calibration Procedures; Step-by-Step pH Calibration

Page 6
2. Operating Modes
If the 901-PH IS NOT fitted with the RS232 option, press the key to roll
through the three operating modes as follows…
pH Mode
7.00pH 25.0 7.00pH 25.0
oo
cc
↓↓
mV Mode
500.0mV 25.0 500.0mV 25.0
oo
cc
↓↓
Temperature Mode
25.0 25.0
oo
cc
↓↓
Back to pH Mode
If the 901-PH IS fitted with the RS232 option, press the key to roll
through the five operating modes as follows…
pH Mode
7.00pH 25.0 7.00pH 25.0
oo
cc
↓↓
mV Mode
500.0mV 25.0 500.0mV 25.0
oo
cc
↓↓
Temperature Mode
25.0 25.0
oo
cc
↓↓
RS232 Send Rate
Send Rate Send Rate ↑↑ 0 0↓↓
↓↓
RS232 Baud Rate
Baud Rate Baud Rate ↑↑96009600↓↓
↓↓
Back to pH Mode
