Trac Vac 580 - Model 580 Trac-Vac Parts List

MODEL 580 Trac-Vac Parts List
Key Part # Description
1 58047 Main Frame
58045 Main Frame, elec.
2 58048 Sub Frame
58046 Sub Frame, 1” axle
3 56021 Engine, 5.5 HP Intek
56022 Engine, 5.5 HP Honda
56018 Engine, 6.5 HP Intek
4 56030 Turbine Housing, 6”
46242 Turbine Housing
5 46253 Turbine, 1” Bore
56040 Turbine, 5 HP
6 58050 Inlet, 6” small back
58036 Inlet, 6” big back
7 58061 Latch
8 58062 Latch Spring
9 58040 Exhaust Hose (Metal)
10 45101 Metal Hose Clamp
11 56070 Cart Connector, 6”
12 58023 Support Arm, 580
13 58022 Support Arm Extension, 15”
14 58072 Hose Support Strap
15 58071 Stand
16 32108 Stand Spring
17 58063 Drawbar
18 58104 Hitch Pin
19 56102 Band Clamp
20 58101 Intake Hose, 6” x 90”
21 560221 Muffler Deflector
22 ***-6 Chute Assembly (Deck Specific)
45131 Decal, 2 x 8 Trac-Vac White
45133 Decal, Warning Stop Engine
58095 Decal, 580 Serial #
86027 Spacer, (580 elec.)
56029 Turbine Spacer, (Honda & elec.)
18110 Key Switch (elec. only)
