-7- TrackIt Limited – V 7.5 April 2013
3 . VT10 Characteristics
Items
Specification
Power Supply +9V - +36V / 1.5A
Backup Battery 850mAh
Normal power consumption 85mA/h
Dimension 104mm x 62mm x 24mm
Installation Dimension 104mm x 83mm x 24mm
Weight 190g
Operating temperature -20° to 55° C
Humidity 5% to 95% Non-condensing
Frequency Quad Band GSM 850/900/1800/1900Mhz
GPS Module latest GPS SIRF-Star III chipset
GPS Sensitivity -158Db
GPS Frequency L1, 1575.42 MHz
C/A Code 1.023 MHz chip rate
Channels 20 channel all-in-view tracking
Position Accuracy 10 meters, 2D RMS
Velocity Accuracy 0.1 m/s
Time Accuracy 1 us synchronized to GPS time
Default datum WGS-84
Reacquisition 0.1 sec., average
Hot start 1 sec., average
Warm start 38 sec., average
Cold start 42 sec., average
Altitude Limit 18,000 meters (60,000 feet) max.
Velocity Limit 515 meters/second (1000 knots) max.
LED 2 LED lights to show GPS/GSM status.
Flash Memory 4MB
Button One SOS Button
Interface 5 digital inputs (3 negative and 2 positive triggering); 2 analog inputs;
5 outputs.
