13
EN
5.1. Blocfor
®
SRL with retrieval
Before using Blocfor
®
for the rst time, it needs to be
installed on its bracket provided for this purpose.
5.1.1. Installation of the Blocfor
®
on the Blocfor
®
Davitrac™ bracket
1. Position the Blocfor
®
anchor point on the bracket
anchor point (See page 3 g. 3b or 3c.), and position
the washer (M) and locknut without tightening them.
2. Place the at-angle bracket on the cable tray of the
Blocfor
®
bracket and adjust it. Then put in place its
mounting screw (See page 3 (g 4a (F) and (G).
3. Tighten the locknut (F) rmly (g. 4.a) and tighten
the screw of the at-angle bracket (G) (g. 4.a).
5.1.2. Installation of the Blocfor
®
Davitrac™ bracket
on the mast of the Davitrac™+ or Davitrac™
1. The Blocfor
®
Davitrac™ bracket is always placed in
the down position on the mast (See page 4 g. 5a):
• At the front if other compliant equipment is used
(See page 3 g. 3c); and
• At the rear if the Blocfor
®
bracket is the only
equipment (See page 3 g. 3b).
2. Position the holes in the bracket inline with the two
holes (L) at the bottom of the mast (See page 4
g. 5a).
3. Insert the pins attached to the bracket into the holes
(See page 4 g. 5a items (L) and (M)).
4. Lock the pins with the safety pins (M) (See page 4
g. 5a items (L) and (M)).
5. Take the cable out of the Blocfor
®
to pass it over
the left pulley guide (B1) if the Blocfor is the only
equipment on the back of the mast or (C1) if the
other compliant equipment is attached. (See page
3 g. (3B) or (3C)).
6. Remove the anti-jump cable pin and position the
cable above the PPE pulley on the anchor head
(D1) (see page 3 g. 3B or 3C).
7. Insert the anti-jump cable pin and lock the safety pin
(see page 3 g. 3B or 3C).
5.1.3. Dismantling of the Blocfor
®
bracket from the
Davitrac™+ or Davitrac™ mast
1. Unlock the anti-jump cable safety pin and remove it
(see page 3 g. 3B or 3C).
WARNING
The cable is automatically brought back by the
Blocfor
®
bracket; be careful of it making any sudden
movements.
2. Remove the cable from the pulleys (see page 3 g
3B or 3C).
3. Remove the safety pins (L) attached to the pins (M)
on the Blocfor
®
bracket (see page 4 g. 5a).
4. Remove the pins (M) from the bracket (see page 4
g. 5a), and hold the bracket and Blocfor
®
bracket to
avoid any damage to the equipment.
5. Replace the pins (M) and safety pins (L) on the
bracket.
5.2. Work winch
Before using work winch for the rst time, it needs to be
installed on its bracket provided for this purpose.
5.2.1. Installation of work winch on the work
winch Davitrac™ bracket
1. Position the work winch on the plate of the work
winch Davitrac™ bracket (see page 3 g 4b).
2. Position the work winch facing the corresponding
holes on the plate of work winch bracket (see page
3 g 4b).
3. Insert the four screws (H) supplied with the bracket
into the holes (see page 3 g 4b).
4. Position the washers on the screws (I) then tighten
the four locknuts rmly (see page 3 g 4b)
5.2.2. Installation of the work winch Davitrac™ bracket
on the mast of the Davitrac™+ or Davitrac™
1. The work winch Davitrac™ bracket is always placed
in the high position (A1) at the rear of the mast (see
page 3 g. 3a).
2. Position the holes in the bracket inline with the two
holes (A) at the top of the mast (see page 3 g. 3a).
3. Insert the pins attached to the bracket into the holes
(See page 4, g 5b, item O).
4. Lock the pins with the safety pins (See page 4, g
5b, item P).
5. Take the cable out of the work winch to pass it over
the right pulley guide ((A1) on the back of the mast
g. (3A) or (3C).
6. Remove the anti-jump cable pin and position the
cable above the lifting pulley on the anchor head
(see page 3 g. 3B or 3C) (for rescue and load lifting
operations or rope access).
7. Insert the anti-jump cable pin and lock the safety pin
(see page 3 g. 3B or 3C).
5.2.3. Dismantling of the work winch Davitrac™
bracket
1. Unlock the anti-jump cable safety pin and remove it
(see page 3 g 3B or 3C).
2. Remove the cable from the pulleys (see page 3 g
3B or 3C).
3. Remove the safety pins attached to the pins on the
work winch bracket (See page 4, g 5b, item P).
