TradeWeld MIG 250M - Technical Specifications; MIG Specifications; TIG Specifications; MMA Specifications

TECHNICAL SPECIFICATIONS
MODEL
MIG 250M
Rated Input Voltage
AC220V±10%
1Phase
Frequency（Hz）
50/60
Rated Input Current
51.6A
MIG
Output Current Range
50A-250A
Output Voltage Range
14V-26.5V
TIG
Output current range
15A – 250A
Output voltage
65V
H.F Function
Trigger start
MMA
Output Current Range
15A-250A
Output Voltage Range
65V
VRD Function
AUTOMATIC
Efficiency（%）
80
Power Factor
0.73
Load Duty Cycle
60% @ 250A
Insulation grade
F
Protection Class
IP21
Cooling method
Fan-cooled
Dimension L x W x H (mm)
830×380×680
Weight （kg）
62
Spool gun connection
Yes
Spool size
5kg-15KG
Wire size
0.8-1.0
