POWER CONNECTION:
POWER NOTES:
Wired to Vehicle Battery:
• Connect the power wire to the vehicle 12V battery and to Endurance II.
• A 1A fuse (not provided) should be used between the power cable and
positve battery terminal when connecting directly to a battery.
• Use zip-ties to secure the cable to the bike as it is routed to Endurance II.
• Connect the red wire to the positive(+) battery terminal, and the black wire
to the negative(-) battery terminal. Endurance II is polarity independent, so
it cannot be installed backwards.
System Tap:
Tap into the electrical system at the lights, ignition, or CDI. When tapping
into the electrical system, connect to a fuse protected circuit. Make sure
power is not interrupted by the key switch when making the connection.
MX Bikes:
Motocross bikes do not have 12 volt power. For connection to an MX bike,
connect power leads to ignition power leads from stator. Use caution, as
this is a high voltage option.
Power Wire
SENSOR
POWER
2000-MANUAL
Tech Support: (844) 378-8143
technicalservice@apexproductgroup.com
1. Wakes on external power from bike.
2. Wakes on wheel movement.
3. Wakes on button press.
4. On external power backlight shuts off after 90 seconds of inactivity.
5. After 180 seconds of inactivity only clock will be displayed.
Endurance II will operate in the range of 9.0-55VDC/9.0-400VAC,
but will not draw enough power to drain a vehicle battery.
