TrailFX RBW10B - Passenger Side Installation Procedure; Final Adjustments and Maintenance Checks

www . T r a il F X . c om
Page 7 of 8 Rev 051918
10. Move to the passenger side of the vehicle. Remove tape covering front, center and rear locations. Repeat Steps 2—9 for
passenger side Running Board installation. NOTE: Refer to the illustration on Page 1 to identify the correct Mounting Bracket
for each of the remaining locations.
11. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
(Fig 17 Driver/Left rear Brackets installed
Rear
(Fig 19) Driver/left front Bracket assembly
(2) 6mm Flat Washers
(2) 6mm Lock Washers
(2) 6mm Hex Nuts
Rear
(Fig 20) Driver/left rear Bracket assembly
(2) 6mm Flat Washers
(2) 6mm Lock Washers
(2) 6mm Hex Nuts
Installation Complete
