DESOTO /WORKER
Assembly Instructions
7. Handlebar
Slide the handlebar (41) through the clamp on the stem
(43) with the portion containing the long bolt to the
rear of handlebar. Install clear reflector. Install the
stem into the fork (39) until the line marked on the
stem is not visible. Align handlebar to the fork as it
faces straight ahead and tighten bolt in stem firmly.
DO NOT over tighten; this can damage the fork tube.
CAUTION: Check that head set (40) is tight.
DO NOT over tighten, however, as this can damage
the fork bearings. Fork assembly should rotate freely.
Slide handbrake lever onto right side of handlebar and
tighten lightly. Slide hand grips (42) on handlebar until
they bottom out. A small amount of soapy water inside
the grip will make installation much easier. NEVER
use oil or other lubricants! Slide handbrake lever
against grip, adjust position and secure tightly.
8. Platform
Place platform (3) onto rear frame, center between the
rear wheels and immediately behind the sissy bar.
Using sheet metal screws (1) and washers (2), secure
the basket to the two holes in the rear frame crossover
tube and two rear holes in the top of the transmission
box. Tighten screws with a 3/8” socket wrench.
9.
Place the
Safety Flag
(4) in flag holder on the
platform frame.
10. Final Check
Review the instructions, check connecting bolts and
screws for tightness, and readjust the seat and
handlebar as necessary.
