Trajan 125 - Parts Lists

CODE NO PART NO DESCRIPTION SPECIFICATION QTY
NOTE
1 125002
Body Frame
1
2 HD901
Nut
M6 4
3 HW104
Spring Washer
M6 4
4 111018
Guide Bracket
1
5 111009
Washer
4
6 CA6072RS
Bearing
607-2RS 8
7 111016 Eccentric Shaft 4
8 111020
Knob
1
9 125025 Adjustable Bracket (Front) 1
10 CA6242RS
Bearing
624-2RS 2
11 111096
Pin
∮4x19.8L 2
12 111031
Washer
4
13 111024A
Blade Cover(Front)
1
14 HS466
Hex. Socker Headless Screw
M8x8L 2
15 111067
Carriage Screw
M6x30L 1
17 HS610
Flat Cross Head Screw
M5x10L 8
18 111060
Bracket
2
19 HW004
Washer
M6 2
20 HW005
Washer
M8 2
21 111014
Knob
1
22-1 ET1244
Limit Switch
1
23 125048 Connecting Tube 1
24 125050A
Blade
1440x13x0.65-8/12T 1
25 125017
Fixed Shaft
1
25-1 HT004
Flat Cross Head Screw
M6x15L 3
26 111004
Drive Wheel
1
27 111072
Washer
1
27-1 111072A
Washer
21.8*15.2-1 1
28 HE506
Hex. Head Screw
M5x10L 4
29 125036
Blade Back Cover
1
32 111022
Tension Bracket
1
33 111028
Press Cake
4
34 HT002
Flat Cross Head Screw
M5x16L 4
35 111056
Spring
1
36 111017
Spring
1
37 111013
Bolt
1
42 111012
Shaft
1
45 E095212
Cable
1
46-3 HS815
Cross Round Head Screw
Ø3.5X35L 2
46-4 111085
Motor Cover
1
PARTS LIST
MODEL NO. 125
12
