Trajan 125 - Motor

CODE NO PART NO DESCRIPTION SPECIFICATION QTY
NOTE
PARTS LIST
MODEL NO. 125
46-5 HS816
Cross Round Head Screw
Ø4X15L 2
46-7 111088A
Separator
1
46-8 111088
Fan
1
46-9 111087A
Bracket
1
46S2 M085 Motor 220V 1
46S2 M085-2 Motor 110V 1
46-1 111084
Brush
2
46-2S 111055AS
Motor Rotor Assembly
1
111055
Motor Rotor Shaft
1
111055B
Motor Rotor
1
46-6S ET2515
Driver Assembly
CF-16(220V) 1
46-6S ET2521
Driver Assembly
CF-16(110V) 1
111090A Bracket 1
57 HS219
Hex. Socket Head Screw
M5x16L 4
58 CAHK0609
Bearing
HK0609 2
59 111032
Washer
3
60 111005
Gear-A
1
61 111044
Bushing
1
62 111006
Gear-B
1
63 111033
Washer
1
64 CAHK0810
Bearing
HK0810 1
66 CA6272RS
Bearing
627-2RS 1
67 111007
Gear-C
1
68 CA6202LLU
Bearing
6202LLU 1
92 HW105
Spring Washer
M8 6
93 HS242
Hex. Socket Head Screw
M8x20L 6
94 111059
Coaster
4
95 HW006
Washer
M10x20x2t 2
96 HB804
Nut
M10 1
97 HS935
Carriage Screw
M10x33L 1
98 HN010
Hex. Nut
M14xP1.5 2
99 111057
Distance Set Rod
1
100 111058
Distance Set Bracket
1
100-1 111097
Plum handle
1
100-2 HS036
Hex. Head Screw
M6x30L 1
101 111045
Angle Margin
2
102 HS527
Cross Round Head Screw
M6x10L 2
104 125033
Degree-Meter
1
105 111116
Rivet
∮3.3X6L 2
107 HS263
Hex. Socket Head Screw
M10x45L 1
13
