4.6 CUTTING TABLE
in a clockwise direction;
-lock the two exagonal nuts R again;
PART RECCOMENDED CUTTING
SPEED
RECCOMENDED
-replace the protective casing, being careful to insert the
blade between the straps of the protection T;
DIMENSIONS TOOTHING CUTTING TIMES
( mm ) ( tooth for inch ) ( m/min ) ( min. sec. )
0’ 40”
60
8/12
30
-reposition the blade guides Pin the correct position for the
next cut.
4.4 CUTTING CAPACITY
The table below specifies the cutting capacity at 0 and 45
degrees which may be obtained in normal conditions of
use described in this manual and without placing any other
object between the jaws of the clamp.
SECTION ANGLE
CUTTING
CAPACITY
122 mm
0 degrees
122 mm
95 mm
-45 degrees
95 mm
63 mm
-60 degrees
63 mm
4.5 CORRECT POSITIONING OF THE PIECE IN THE
CLAMP
The pieces to be cut should be fitted directly between the
jaws without adding other objects.
ATTENTION : Never hold the pieces to be cut in your
hand.
When the pieces to be cut are profiled sections, flat pieces
or special shapes, refer to the examples shown in the
figures.
If the thickness of the profiled section is to be very thin, an
outline should be fitted which copies the profile inside the
profiled section itself to stop it being crushed between the
jaws.
50
85
6
6
60
60
2’ 00”
5’ 00”
1’ 10”
60
8/12
30
50
85
6
6
60
60
2’ 10”
8’ 00”
1’ 10”
60
8/12
25x35
40x50
85x105
6
6
60
60
2’ 30”
11’ 00”
0’ 05”
80
18
30 x s. 1
40 x s. 2
50 x s. 5
14
8/12
80
80
0’ 15”
0, 50”
30 x s. 1
18 80 0’ 10”
50 x s. 2
14 80 0’ 30”
5.0 ACCESSORIES
5.1 CHOISE OF BLADE
Your sawing machine is equipped with a bi-metal blade
measuring 1440 * 13 * 0.65 mm with variable toothing 10t
teeth per inch, for use in the majority of cuts possible with
this machine.
For special requirements (see cutting table point 4.6), for
example, for cutting large solid sections or profiled
sections or corner pieces of small thickness, there are also
blades avail-able with 6, 10, 14 or 18teeth per inch.
MATERIAL: M42 (acciaio per molle + acciaio HSS)
EXTENSION: mm 1440
HEIGHT: mm 13
THICKNESS: mm 0.65
TOOTHING: standard 10 optional 6- 14 –18 –10-8/12
6.0 MAINTENANCE
6.1 REGULAR MAINTENANCE
The operations of ordinary maintenance, which may also
be performed by non-specialist personnel, are all
described in the previous sections and here below.
1.Before performing any maintenance operation,
disconnect the machine electric plug from the wall
outlet.
2.During maintenance operations, always wear personal
protection (safety goggles and gloves).
3.Remove the processing residues from the cutting area
and the blade guides whenever necessary.
You are advised to use a suction device or a brush.
Do not use jets of compressed air.
4.If you do not intend to use the sawing machine for a long
time, clean it and put it in a dry place if possible.
In these cases it is advisable to slacken off the blade so
that it is not kept tight for no reason.
