16
BAS-SVN029C-EN
Table 5. TR170 VFD drive parameters Ipak II (continued)
Parameter Number Parameter Description Ipak II Setting Units
4-10 Motor Speed Direction Clockwise (0) —
4-12 Motor Speed Low Limit [Hz] 22 Hz
4-14 Motor Speed High Limit [Hz] 60 Hz
4-18 Current Limit 137 %
5-12 Terminal 27 Digital Input Coast and reset inverse (3) —
5-40 Function Relay Default Value —
6-10 Terminal 53 Low Voltage 0 V
6-14
Terminal 53 Low Ref./Feedb. Value
22 —
6-15 Terminal 53 High Ref./Feedb. Value 60 —
14-01 Switching Frequency 5 kHz
14-12 Function at Mains Imbalance De-rate (3) —
14-20 Reset Mode Auto reset x3 (3) —
14-21 Automatic Restart Time 5 s
14-50 RFI Filter Off (0) —
Note: *60 or 50Hz for Pueblo Production, 50Hz for Charmes production. Otherwise, set for maximum speed rating of motor/fan.
The following table defines the complete set of parameters for the TR170 VFD drives used in
condenser fan applications on CGAM products.
Table 6. TR170 VFD drive parameters CGAM
Parameter Number Parameter Description CGAM Setting Units
0-03 Regional Settings North America for 60 Hz, International for 50
Hz
—
0-06 Grid Type Depends on Grid Type —
0-40 [Hand on] Key on LCP Disable (0) —
1-20 Motor Power
(Motor Specific) kW
1-22 Motor Voltage (Motor Specific) V
1-23 Motor Frequency
(Motor Specific)
Hz
1-24 Motor Current
(Motor Specific)
A
1-25 Motor Nominal Speed (Motor Specific) RPM
1-71 Start Delay 3 s
1-72 Start Function DC Hold (0) —
1-73 Flying Start Default Value —
1-82
Min Speed for Function at Stop [Hz]
0.1 Hz
1-90 Motor Thermal Protection ETR Trip 1 (4) —
2-00 DC Hold/Motor Preheat Current Default Value %
2-02 DC Braking Time Default Value s
2-10 Brake Function Off (0) —
3-03
Maximum Reference 50/60
—
IInnssttaalllliinngg TTRR117700 VVFFDD aanndd CCoommppoonneennttss
