Table 6. TR170 VFD drive parameters CGAM (continued)
Parameter Number Parameter Description CGAM Setting Units
3-16 Reference 2 Source No function (0) —
3-17
Reference 3 Source No function (0)
—
3-41 Ramp 1 Ramp Up Time 5 s
3-42 Ramp 1 Ramp Down Time 20 s
4-10
Motor Speed Direction Clockwise (0)
—
4-12 Motor Speed Low Limit [Hz] 5/6 Hz
4-14 Motor Speed High Limit [Hz] 50/60 Hz
4-18 Current Limit
If p122 = 460V then 115 Else 110
%
5-12
Terminal 27 Digital Input No operation (0)
—
5-40 Function Relay Alarm (9) —
6-10 Terminal 53 Low Voltage 1 V
6-14 Terminal 53 Low Ref./Feedb. Value 5/6 —
6-15 Terminal 53 High Ref./Feedb. Value 50/60 —
14-01 Switching Frequency 5 kHz
14-12 Function at Mains Imbalance De-rate (3) —
14-20 Reset Mode Auto Reset x10 (10) —
14-21 Automatic Restart Time 30 s
14-50 RFI Filter Off (0) —
Note: *60 or 50Hz for Pueblo Production, 50Hz for Charmes production. Otherwise, set for maximum speed rating of motor/fan.
Copying Parameters to Multiple Drives
If you are installing multiple drives, the drive LCP (local control panel) can be used to copy
parameters from one drive to another. This method can save time and reduce errors.
UUppllooaaddiinngg DDaattaa ttoo tthhee LLCCPP
1. Go to 0-50 LCP copy.
2. Press OOKK.
3. Select AAllll ffrroomm LLCCPP.
4. Press OOKK.
A progress bar shows the uploading process
5. Press HHaanndd oonn to return to normal operation.
Remove the LCP from the configured drive and install it on the unconfigured drive.
DDoowwnnllooaaddiinngg DDaattaa ffrroomm tthhee LLCCPP
1. Go to 0-50 LCP copy
2. Press OOKK
3. Select AAllll ffrroomm LLCCPP
4. Press OOKK.
A progress bar shows the uploading process
5. Press HHaanndd oonn to return to normal operation.
IInnssttaalllliinngg TTRR117700 VVFFDD aanndd CCoommppoonneennttss
