Table 7. TR170 VFD IntelliPak II™ wiring schematics and connection diagrams (continued)
Wiring Diagram
Number
Description
1213-1573 CONNECTION, CONTROL BOX - 120-150T, W/EXH/RTN VFD W/ LOW AMBIENT
1213-1574 CONNECTION, CONTROL BOX - 120-150T, W/SUP & EXH/RTN VFD W/ LOW AMBIENT
1213-1575 CONNECTION, CONTROL BOX - 120-150T, STANDARD W/ LOW AMBIENT
1213-1576 CONNECTION, CONTROL BOX - 120-150T, W/SUPPLY VFD W/ LOW AMBIENT
1213-1577 CONNECTION, CONTROL BOX - 120-150T, W/EXH/RTN VFD W/ LOW AMBIENT
1213-1578 CONNECTION, CONTROL BOX - 120-150T, W/SUP & EXH/RTN VFD W/ LOW AMBIENT
NNoottee:: Wiring diagrams are available via e-Library (if accessible) or contact the local Trane
representative to obtain a copy.
Table 8. TR170 VFD CGAM™ wiring schematics and connection diagrams
Wiring Diagram
Number
Description
2309–2075 SCHEMATIC; CGAM, S, V, W
NNoottee:: Wiring diagrams are available via e-Library (if accessible) or contact the local Trane
representative to obtain a copy.
Table 9. TR170 VFD RTAC™ wiring schematics and connection diagram
Wiring Diagram
Number
Description
2309–2097 RTAC; 2 COMPRESSOR
2309–4621 RTAC; 3 COMPRESSOR, X-LINE STARTER
2309–4622 RTAC; 3 COMPRESSOR, WYE-DELTA STARTER
2309–4623 RTAC; 4 COMPRESSOR, X-LINE STARTER
2309–4624 RTAC; 4 COMPRESSOR, WYE-DELTA STARTER
NNoottee:: Wiring diagrams are available via e-Library (if accessible) or contact the local Trane
representative to obtain a copy. See the Series R Air-Cooled Helical Rotary Liquid Chillers
Wiring Manual (RTAC-SVE01*-EN) (Refer to version E or subsequent versions).
WWiirriinngg DDiiaaggrraamm MMaattrriixx
