Trane Technologies RTAG 225 - Page 11

CHHP = GP2 compressor series
0N2 = 120 TON
0N1 = 100 TON
0M2 = 85 TON
0M1
Unit Model Number
= 70 TON
0L2 = 60 TON
0L1 = 50 TON
0K2 = 40 TON
0K1 = 35 TON
A = 200-60-3
R = 220-50-3
C = 230-60-3
D = 380-60-3
H = 575-60-3
T = 460-60-3 OR 400-50-3
K = 450 psid
** = Factory assigned
N = Standard Capacity Controls
112 = 112 kW (N2/50Hz)
093 = 093 kW (N1/50Hz)
077 = 077 kW (M2/50Hz)
065 = 065 kW (M1/50Hz)
058 = 058 kW (L2/50Hz)
048 = 048 kW (L1/50Hz)
041 = 041 kW (K2/50Hz)
036 = 036 kW (K1/50Hz)
A = High Volume Ratio
10 RTAG-SVX001H-EN
N = Low Volume Ratio
CHHW = GP2.5 Compressor Family
0 = All compressors
N = N Frame
5 = GP2.5 Smaller capacity (minor)
6 = GP2.5 Larger capacity (major)
T = 400/460-50/60-3 used for 380-50-3
K = 460-60-3 (N6 only)
K = 450 psid
** = Factory assigned
N = Standard capacity
093 = N5 50Hz
112 = N5 60Hz
112 = N6 50Hz
134 = N6 60Hz
A = HighVolume Ratio
