Compressor 1
Compressor 2
(With fan/coil removed)
Locate Customer Power
Lifting Point
Outlet
Inlet
Lifting Point
Installation
Installation Point
Control Panel
TD7
Unit
Water
Box
H1
(mm)
H2
(mm)
W1
(mm)
W2
(mm)
L1
(mm)
L2
(mm)
Water pipe
L
(High eff)
(Extra eff)
(mm)
L
(Premium Seasonal eff)
(mm)
RTAG225P
150psi 450 465 1275 970 3938 3938 7380 7510
6"
Figure 2. Dimension - RTAG 225 Premium efficiency unit
18 RTAG-SVX001H-EN
