Trane Technologies RTAG 225 - Page 20

Dimension
Unit
Water
Box
H1
(mm)
H2
(mm)
W1
(mm)
W2
(mm)
L1
(mm)
L2
(mm)
L
(mm)
Water pipe
RTAG 230P 150psi 450 465 1275 970 5118 5118 8732 6“
Figure 3. Dimension - RTAG 230 Premium efficiency unit
RTAG-SVX001H-EN 19
