88-4TCA4001-1C-EN
4TCA4042A1 ESP 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Low
CFM 1458 1392 1316 1240 1166 1076
WATTS 252 263 273 284 295 311
Medium
CFM 1520 1461 1390 1322 1256 1184 1090
WATTS 287 298 309 320 331 343 359
High
CFM 1572 1514 1457 1401 1340 1256 1189
WATTS 461 473 486 498 510 529 539
4TCA4048A1 ESP 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Low
CFM 1578 1525 1467 1413 1348 1261 1201
WATTS 325 335 344 353 363 383 392
Medium
CFM 1670 1605 1541 1486 1429 1395 1312 1256 1196
WATTS 380 393 406 420 432 443 454 463 472
High
CFM 1795 1715 1701 1641 1585 1508 1458
WATTS 602 628 623 637 650 677 689
4TCA4060A1/B1 ESP 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Low
CFM 1746 1673 1596 1525
WATTS 385 401 418 432
Medium
CFM 1965 1895 1799 1762 1697 1635 1580 1532
WATTS 516 534 554 572 588 602 617 624
High
CFM 2020 1960 1927 1852 1819 1771 1724
WATTS 771 792 807 822 838 850 864
FFiinnaall IInnssttaallllaattiioonn CChheecckklliisstt
IImmppoorrttaanntt:: Perform a final unit inspection to be sure
that factory tubing has not shifted during
shipment. Adjust tubing if necessary so
tubes do not rub against each other when
the unit runs. Also be sure that wiring
connections are tight and properly secured.
☐ Does the unit run and operate as described in the
Sequence of Operation section in response to the
room thermostat?
☐ Are the condenser fan and indoor blower operating
correctly with proper rotation and without undue
noise?
☐ Is the compressor operating correctly and has the
system been checked with a charging chart?
☐ Has the voltage and running current been checked
to determine if it is within limits?
☐ Has the thermostat been checked for calibration
and the air discharge grills adjusted to balance the
system?
☐ Has the ductwork been checked for air leaks and
condensation?
☐ Has the furnace manifold pressure been checked
and adjusted if necessary?
☐ Has the heating air temperature rise been checked?
☐ Has the unit been checked for tubing and sheet
metal rattles? Are there any other unusual noises to
be checked?
☐ Are all covers and panels in place and properly
fastened?
☐ Has the owner been instructed on the proper
operation and maintenance of the unit? Be sure to
leave this manual with the owner.
SSeeqquueennccee ooff OOppeerraattiioonn
