6 18-GE12D1-8
Installer’s Guide
WHEN INSERTING COIL, TILT COIL FORWARD TO ALLOW
DRAINPAN TO CLEAR TABS ON COIL CHANNEL SUPPORTS.
FOR DOWNFLOW OR HORIZONTAL LEFT APPLICATIONS:
DRAINPAN SHOWN
IN PLACE
TAB - AS MOUNTED
ON COIL CHANNEL
SUPPORT
Figure 10
TO REMOVE BLOWER ASSEMBLY WHEN COIL IN
PLACE, PRESS UP ON COIL USING THUMBS
WHILE PULLING BLOWER FORWARD.
Figure 12
Figure 11
