Floor standing indoor unit with DC fan motor
3
2. Specifications
Model
4TVS0007DF000A 4TVS0009DF000A 4TVS0012DF000AA
Power supply V- 220-240V, 1Ph, 50/60Hz
Coolin
g
Capacity kW 2.2 2.8 3.6
Input W 24 24 21
Rated current A 0.18 0.21 0.22
Heatin
g
Capacity kW 2.6 3.2 4.0
Input W 23 24 19
Rated current A 0.18 0.21 0.22
Indoor
fan
motor
Model WZDK100-38GS-2
Type DC motor
Brand Panasonic/Welling/Shibaura Panasonic/Welling/Shibaur
Input W 26 29 22
Output W
21 22 17
Speed (h/m/l) r/min 950/820/730 990/870/770 790/700/570
Indoor
coil
Number of rows 2 2 3
Tube pitch(a)x row mm 25.4*22 25.4*22 25.4*22
Fin spacing mm 1.8 1.8 1.8
Fin type Hydrophilic aluminum
Tube outside diameter mm Ф9.52 Inner grooved tube
Coil length*height*width mm 568*254*44 568*254*44 768*254*66
Number of circuits 3 3 3
Indoor air flow (H/M/L) m
3
/h 530/456/400 569/485/421 624/522/375
Indoor noise level (H/M/L) dB(A) 36/33/29 36/33/29 37/34/30
Indoor
unit
Dimension (W*H*D) mm 840*545*212 840*545*212 1040*545*212
Packing (W*H*D) mm 939*639*305 939*639*305 1139*639*305
Net/Gross weight kg 21/25 21/25 28/33
Refrigerant type R410A
Throttle
Type EXV (Built-in)
Mode D20MISZ-1R(L)
Design pressure MPa 4.4/2.6
Refrigerant Liquid side/ Gas mm
Connecting
Power wiring mm
2
3*2.5(L≤20m); 3*3.5(L≤50m)
Signal wiring mm
2
3*0.75
Drainage water pipe diameter mm ODФ25
Notes: 1.Nominal cooling capacities are based on the following conditions: return air temperature : 27°CDB, 19°CWB, outdoor
temperature:35°CDB,equivalent ref. Piping: 8m(horizontal).
2.Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB,outdoor
temperature: 7°CDB,6°CWB,equivalent ref. Piping: 8m(horizontal)
3. Specifications of F3 series are measured at 10Pa external static pressure.
