Trane 4TVS0007DF000A - Page 6

Floor standing indoor unit with DC fan motor
5
Model
4TVS0024DF000AA
4TVS0027DF000AA
Power supply V- 220-240V, 1Ph, 50/60Hz
Cooling
Capacity kW 7.1
8.0
Input W 62
62
Rated current A 0.56
0.59
Heating
Capacity kW 8.0
9.0
Input W 65
63
Rated current A 0.56
0.59
Indoor
fan
motor
Model WZDK100-38GS-3
WZDK100-38GS-3
Type
DC motor
Brand
Panasonic/Welling/Shibaura Panasonic/Welling/Shibaura
Input W
90 86
Output W
72 69
Speed (h/m/l) r/min
1140/1040/910 1140/1040/910
Indoor
coil
Number of rows
2 3
Tube pitch(a)* row pitch(b) mm
25.4*22 25.4*22
Fin spacing mm
1.8 1.8
Fin type
Hydrophilic aluminum
Tube outside diameter and type mm
Φ9.52 inner grooved tube
Coil length*height*width mm
1068*254*44 1068*254*66
Number of circuits
4 3
Indoor air flow (H/M/L) m3/h
1380/1100/870 1380/1100/870
Indoor noise level (H/M/L) dB(A)
44/39/33 44/39/33
Indoor
unit
Dimension (W*H*D) mm
1340*545*212 1340*545*212
Packing (W*H*D) mm
1425*639*305 1425*639*305
Net/Gross weight
kg 32/38 35/39
Refrigerant type
R410A
Throttle
Type
EXV (Built-in)
Model
D20MISZ-1R(L)
Design pressure MPa
4.4/2.6
Refrigerant piping Liquid side/ Gas mm
Ф9.53/Ф16 Ф9.53/Ф16
Connecting wiring
Power wiring mm
2
3*2.5(L≤20m); 3*3.5(L≤50m)
Signal wiring mm
2
3*0.75
Drainage water pipe diameter mm ODФ25
Notes: 1.Nominal cooling capacities are based on the following conditions: return air temperature : 27°CDB, 19°CWB, outdoor
temperature:35°CDB,equivalent ref. Piping: 8m(horizontal)
2.Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB,outdoor
temperature: 7°CDB,6°CWB,equivalent ref. Piping: 8m(horizontal)
3.Specifications of F3 series are measured at 10Pa external static pressure.
