Trane 4TXK3812A1 - Outdoor Heat Pump Only Unit 9 K-12 K Wiring

Outdoor Heat Pump Only Unit 9K-12K
NOTE: The wiring diagrams in this guide are included as a reference. The manufacturer
has a policy of continuous product and product data improvement and reserves the
right to change design and specifications without notice. Always check the unit
nameplate and wiring diagram for the actual unit requirements.
6361000044501
N(1)
2
3
32
38 Series Mini-Split
