Trane 4TXK6548G1000AA - Page 11

36K 48K
TRANE Model 4MXX6536G1000AA 4MXX6548G1000AA
Power supply V-ph-Hz
220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max) Btu/h 14,000 ~ 36,000 ~ 37,000 19,200 ~ 47,000 ~ 50,500
Capacity (min ~ nor ~ max)
W
4,100 ~ 10,550 ~ 10,840 5,625 ~ 13,770 ~ 14,800
Input
W 3,149 4,211
EER W/W
3.35 3.27
Heating
Capacity (min ~ nor ~ max) Btu/h 14,500 ~ 36,500 ~ 42,300 19,500 ~ 48,500 ~ 51,300
Capacity (min ~ nor ~ max)
W
4,248 ~ 10,695 ~ 12,395 5,710 ~ 14,210 ~ 15,030
Input
W 3,342 4,440
COP
W/W
3.20 3.20
Indoor fan motor
Model ZWK511A800054 ZWK511B500030
Qty
1 1
Input
W 120 150
Capacitor uF / /
Speed(Hi/Med/Lo) r/min 1050/950/900 1030/950/870
Indoor coil
Number of rows
2 2
Tube pitch(a)x row pitch(b)
mm 21×18.186 21×18.186
Fin spacing
mm 1.3 1.3
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type
mm
φ7 / Inner grooved φ7 / Inner grooved
Coil length x height x width
mm 1007×294×36.37 1333×294×36.37
Number of circuits
7 7
Indoor air flow(Hi/Med/Lo)
m
3
/h
1820/1750/1600 2150/1980/1800
Indoor noise level (sound pressure)(Hi/Med/Lo) dB(A) 52/49/46 52/49/46
Throttle type In ODU In ODU
Indoor unit
Dimension (WxDxH)
mm 1325×680×230 1650×680×230
Packing (WxDxH)
mm 1425×779×305 1750×779×305
Net/Gross weight kg 33.5/41.9 41.8/49.5
Design pressure MPa 4.15/1.5 4.15/1.5
Drainage water pipe diameter
mm 25 25
Refrigerant piping Liquid side/Gas side mm(inch) 9.52/19.05 9.52/19.05
Controller Remote control Remote control
Operation temperature
°C
16~30 16~30
Room temperature
Cooling
°C
18~32 18~32
Heating
°C
15~27 15~27
Qty’per 20’ /40’ /40'HQ (indoor unit) 84/168/192 63/133/152
2
