Model: 4MXD6548G1000AA 4MXD6548G1000AA 4MXD6560G1000AA
PCB CODE:0151800106G
SW01(1-ON,0-
OFF)
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
Description
ON ON ON
-- -- -- -- --
4MXD6536G1000AA
ON ON
OFF -- -- -- -- --
4MXD6548G1000AA
ON ON
OFF -- -- -- -- --
4MXD6560G1000AA
-- -- -- OFF -- -- -- --
Room card unavaible( default)
-- -- -- ON -- -- -- -- Room card avaible
-- -- -- -- OFF -- -- --
Heating pump(default)
-- -- -- --
ON
-- -- --
Cooling only
-- -- -- -- -- OFF
Temperature compensate unavaible( default)
-- -- -- -- --
ON Temperature compensate avaible
-- -- -- -- -- --
ON
OFF
Duct
SW03(1
-
ON,0
-
OFF)
Indoor unit address No.in group controller
SW3-1 SW3-2 SW3-3 SW3-4
OFF OFF OFF OFF
0#(master unit)
OFF OFF OFF
ON 1#(slave unit)
OFF OFF
ON
OFF
2#(slave unit)
OFF OFF
ON ON 3#(slave unit)
OFF
ON
OFF OFF
4#(slave unit)
OFF
ON
OFF
ON 5#(slave unit)
OFF
ON
ON
OFF
6#(slave unit)
OFF
ON ON ON 7#(slave unit)
ON
OFF OFF OFF
8#(slave unit)
ON
OFF OFF
ON 9#(slave unit)
ON
OFF
ON
OFF
10#(slave unit)
ON
OFF
ON ON 11#(slave unit)
ON ON
OFF OFF
12#(slave unit)
ON ON
OFF
ON 13#(slave unit)
ON ON ON
OFF
14#(slave unit)
ON ON ON ON 15#(slave unit)
125
