C l e a r a n c e
i s n o t e
alowed
Clearan
If the elevation level of the indoor unit and drain pipe are not affected, you can adjust the height of the indoor unit
allowed
through the corner pore on the trim panel . Please keep the unit horizontal in the process of adjustment, or
else water leakage is easy to occur .
Please do not swing the louver blade by hand, or else the blade mechanism would be damaged .
6) Connection of trim panel . Connect the black lead-out terminal of the panel to the black lead-out terminal of the
i n d o o r u n i t h o u s i n g . t
onnecino the pa
Connecting terminal
Indoor unit Connecting to the panel side
Trim panel onnecinerminal
Connecting
t
o the
in unit side
Connecting to the indoo
unit side
7) When the installation of panel is complete, please fix the four (4) angle trim panels .
Hang and tighten the strap of the angle trim panel on the shackle of the trim panel, as shown in the figure .
Fix the angle trim panel on the trim panel .
7 1
