48K 60K
TRANE Model 4MXD6548G1000AA 4MXD6560G1000AA
Power supply V-ph-Hz
220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max) Btu/h
19,000 " 48,000 " 50,000 20,000 " 50,500 " 54,000
Capacity (min ~ nor ~ max)
W
5,567 " 14,064 " 14,650 5,860 " 14,800 " 15,822
Input
W
4,642 4,884
EER W/W
3.03 3.03
Heating
Capacity (min ~ nor ~ max) Btu/h
19,000 " 48,500 " 50,300 20,100 " 52,600 " 58,000
Capacity (min ~ nor ~ max)
W
5,567 " 14,210 " 14,738 5,890 " 15,412 " 17,000
Input
W
4,737 5,138
COP
W/W
3.00 3.00
Indoor fan motor
Model
Y7S423C21 ZWK702B500025
Qty
1 1
Input
W
280 375
Speed(Hi/Med/Lo) r/min
1260/1145/1100 1400/1300/1200
Indoor coil
Number of rows
4
3
Tube pitch(a)*row pitch(b)
mm
21×13.3 21×13.3
Fin spacing
mm
1.3 1.8
Fin type
Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type
mm
c17 / Inner grooved c17 / Inner grooved
Coil length * height * width
mm
1001×294×39.9 1062×425×39.9
Number of circuits
10 5
Indoor air flow (Hi/Med/Lo)
m
2090/1097/1792 2600/2200/1950
ESP
Rated Pa
100 100
Range Pa
10-100 10-100
Indoor noise level (Hi/Med/Lo) dB(A)
49/47/44 52/47/42
Throttle type
In ODU In ODU
Indoor unit
Dimension (WxDxH)
mm
1140×710×275 1197×650×360
Packing(WxDxH)
mm
1342×841×358 1345×770×390
Net/Gross weight kg
46/52 56/59
Design pressure MPa
4.15/1.5 4.15/1.5
Drainage water pipe diameter
mm
38 38
Refrigerant piping Liquid side/ Gas side
mm
9.52/19.05 9.52/19.05
Controller
Wired control Wired control
Operation temperature
℃
16"30 16"30
Room temperature
Cooling
℃
18"32 18"32
Heating
℃
15"27 15"27
Qty’per 20’ /40’ /40'HQ
66/132/154 60/125/150
Remarks:1.The above design and specifications are subject to change without prior notice for product improvement.
