Trane A952V040BU3SAB - Page 94

94
88-A952V001-1D-EN
1. Remove two 3” plugs on left side of cabinet. To be used for
combustion air exhaust and inlet.
2. Reuse the two 3” plugs to seal the two 3” default openings on the
top of the cabinet.
1. Loosen the clamp holding the 45° elbow. Remove the elbow and
discard.
FFuurrnnaaccee CCoommbbuussttiioonn AAiirr EExxhhaauusstt OOppttiioonnss
