5UNT-SVU001-EN
Wireless Remote Control
Battery: Two AAA batteries are used in
this remote control unit.
Infrared Remote Control
Name and function of
buttons
1. Infrared signal transmitter
Transmits the signal to indoor unit.
2. MODE Button
Press this button to select system
operating modes. In cooling only
system, a mode is selected in a
sequence as FAN, COOL, DRY
and back to FAN. In cooling and
heating system, a mode is
selected in a sequence as FAN,
COOL, DRY, HEAT, AUTO and
back to FAN.
3. SWEEP Button
Press this button to activate sweep
motor to distribute air flow (not
available in all models).
4. LOUVER Button
Press this button to adjust the
direction of air flow.
5. POWER Button
Press this button to start operation.
Press the button again to stop
operation.
6. Temperature Setting Button
TEMP ▲ :Press this button to
increase the set temperature.
TEMP ▼ :Press this button to
decrease the set temperature.
7. FAN Button
Press this button to select fan
speed.
8. SLEEP Button
Press this button to control
temperature while sleeping.
9. CLOCK Button
This button is used to set the
clock. If button is pressed during
18.00 hrs. to 6.00 hrs., it will turn
on the back light. If there is no
button pressed within 3 seconds,
the back light will be turn off.
10. STOP Button
Press this button to set the OFF
timer.
11. START Button
Press this button to set the ON
timer.
12. MIN Button
This button is used to set the
minute.
13. HOUR Button
This button is used to set the hour.
14. SEND Button
This button is used to confirm the
programming on the remote unit
to the fan coil unit.
ON OFF
2
3
4
12
13
5
6
1
7
8
9
10
11
14
