Trane BAYEVBC20BK1A - Heater Model Number Matrix - Step 2

Page 4
INSTALLER'S GUIDE
Step 2 - Use the Heater Model Number Matrix to de-
termine which heaters will fit in your cabinet and to
determine if you will have to modify the heater to fit the
cabinet.
Electric Heat Model Number
Digit 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Example
B A Y E V A C 1 5 B K 1 A A A
Brand Both Brands B
Product Type Accessory A Y
Heat Type Electric Heater E
Product Tier Air Handler Tier
(7 and 8)
V
Size
(Footprint)
Minimum Cabinet
Width (A,B,C)
A
Maximum Cabinet
Width (A,B,C)
C
Electric Heat Input Electric Heat - kW (05,
08, 10, 15, 20, 25)
0-9 0-9
Connection Breaker B K
Lugs L G
Power Supply 208-230/1/60 1
200/1/50 A
208-230/3/60 3
Major Design Modifications Letter Sequence A
Minor Design Modifications Letter Sequence A
Unit Parts Identifier Letter Sequence A
Record Your Heater Size = _________
The heater in this example will fit into cabinets A, B, & C.
From Step 1 we know that the heater needs to be sized
to fit in a B cabinet.
See Section 5 for instructions for modifying your heater
to fit various cabinet sizes.
This matrix is provided as an example only.
