Operator
Interface
Report name: System ASHRAE Chiller Log
Description Resolution Units Dependencies
1. Current Time/Date XX:XX mmm dd, yyyy Date / Time
2. Chiller Mode: Enum
3. Active Chilled Water Setpoint: XXX.X Temperature
4. Active Current Limit Setpoint: XXX % RLA
5. Refrigerant Type: Enum
6. Refrigerant Monitor: XXX.X PPM If option installed
7. Evap Entering Water Temp: XXX.X Temperature
8. Evap Leaving Water Temp: XXX.X Temperature
9. Evap Water Flow Switch Status: Enum If option not installed
10. Evap Differential Wtr Press: XXX.X Diff Pressure If option installed
11. Approx Evap Water Flow: XXX.X GPM/LPM If option installed
12. Approx Chiller Capacity: XXXX Capacity If option installed
13. Cond Entering Water Temp: XXX.X Temperature
14. Cond Leaving Water Temp: XXX.X Temperature
15. Cond Water Flow Switch Status: Enum If option not installed
16. Cond Differential Wtr Press: XXX.X Pressure
17. Approx. Cond Water Flow: XXXX Flow If option installed
Report name: Circuit ASHRAE Chiller Log
Description Resolution Units Dependencies
1. Circuit Operating Mode: Enum
2. Amps L1 L2 L3 XXXX Amps XXX.X if less than
1000 Amps
3. Volts AB BC CA XXXX Volts
4. Purge Daily Pumpout –24 Hrs: XXX.X Min
5. Purge Daily Pumpout Limit/Alarm XXX.X Min
6. Purge Pumpout - Life XXXXXX.X Min
7. Purge Operating Mode: Enum
8. Purge Status: Enum
9. Compressor Starts: XXXX Integer
10. Compressor Running Time: XX:XX Hours:Minute
11. Compressor Rfgt Discharge Temp: XXX.X Temperature If option installed
12. Oil Pump Discharge Pressure: XXX.X Pressure
13. Oil Tank Pressure: XXX.X Pressure
14. Differential Oil Pressure: XXX.X Diff Pressure
15. Oil Tank Temp: XXX.X Temperature
16. Inboard Bearing Temp: XXX.X Temperature If option installed
17. Outboard Bearing Temp: XXX.X Temperature If option installed
18. Evap Sat Refrigerant Temp: XXX.X Temperature
19. Evap Rfgt Pressure: XXX.X Pressure
20. Evap Approach Temp: XXX.X Temperature
21. Cond Sat Rfgt Temp: XXX.X Temperature
22. Cond Rfgt Pressure: XXX.X Pressure
23. Condenser Approach Temp: XXX.X Temperature
Historic Diagnostics Log
1 to 20 Historic Diagnostics (main processor 2.0 and later)
