General
Information
V = 1890
W = 2060
X = 1475
Z = 560 - 3 stage 935 - 2 stage
Y = 500 - 3 stage 835 - 2 stage
1 = 630 - 3 stage 2245 - 2 stage
2 = 800 - 3 stage 2345 - 2 stage
3 = 900 - 3 stage 2450 - 2 stage
4 = 1000 - 3 stage 2560 - 2 stage
5 = 1120 - 3 stage 2675 - 2 stage
6 = 1250
7 = 1600
8 = 1800
9 = 750
34
th
A = Starter Type
A = Star-Delta Unit Mounted
C = Star Delta Remote Mounted
E = X-Line Full Volt Remote Mounted
F = Autotransformer Remote
Mounted
G = Primary Reactor Remote
Mounted
H = X-Line Full Volt Unit Mounted
J = Autotransformer Unit Mounted
K = Primary Reactor Unit Mounted
L = Solid State Unit Mounted
M = Solid State Floor Mounted
N = Solid State Wall Mounted
P = Adaptive Freq. Drive-Unit
Mounted
R = Customer Supplied
35
th
C = Control Enclosure;
C = Standard
S = Special
36
th
1 = Control: Enhanced Protection;
0 = None
1 = Enhanced protection
37
th
G = Control: Generic BAS;
0 = None
G = Generic BAS
38
th
W = Water Flow Control;
0 = None
W = Water flow control
39
th
4 = Tracer
®
Comm. Interface
0 = None, 4 = COMM 4,
5 = COMM 5, S = Special
40
th
C = Control: Condenser
Refrigerant Pressure;
0 = None, C = with
41
st
1 = Control: Extended Operation;
0 = None
1 = Extended operation
42
nd
1 = Chilled Water Reset -
Outdoor Air Temperature Sensor
0 = None,
1 = Chilled water reset – with outdoor
air temperature sensor,
S = Special
43
rd
1 = Control: Operating Status,
0 = None,
1 = Operating Status
44
th
1 = Gas Powered Chiller;
0 = No
1 = Yes
45
th
3 = Compressor Motor Frame
Size LH Circuit
46
th
4 = Compressor Motor Frame
Size RH Circuit
FRAME SIZE CODES: 3 = 440E, 4 =
5000, 5 = 5800, 6 = 5800L, S = Special
47
th
0 = Unit Insulation;
0 = None
1 = Insulation package
48
th
A = Spring Isolators
0 = No
A = Yes
49
th
0 = Not Assigned
0 = Not assigned
50
th
1 = Evaporator & Condenser Size
1 = 210D - 2100,
2 = 250D – 2500,
3 = 250X - 2500 ,
4 = 250M - 2500
51
st
0 = Special Options
0 = None
S = Special Option
