Trane FD145CLFR000D User Manual

26 Numbers in [brackets] are for 50 Hz international systems. Pub. No. 18-HE53D1-11
Installer’s Guide
Dimensions
(all dimensions in inches)
2.8”
21
18.88
21” DEPTH CABINET
ADD DOOR DEPTH FOR TOTAL
Front
of
Cabinet
Side View
OUTLINE DRAWING FOR AIR HANDLERS
AIR HANDLER MODEL NUMBERS
ifD Air Cleaner A
B (multiple
piece cabinet)
B (one piece
cabinet)
*FD175CLAH000D 17.5 14.9 15
*FD215CLAH000D
TFD215CLAH005D
21.5 18.9 19
*FD235CLAH000D
TFD235CLAH005D
23.5 20.9 21
*FD260CLAH000D
TFD260CLAH005D
26.0 23.4 23.5
* May be "A" or "T"
