General Information
Table 4. FIADAST004* Y/D models (digit 39 = B)
Qty Description
1 Temperature sensing module
5 Sensing tubes
4 Mounting brackets
1 Pipe insulation
16 Screws
Table 5. FIADAST005* T/W models (digit 39 = C)
Qty Description
1 Temperature sensing module
6 Sensing tubes
3 Mounting brackets
1 Pipe insulation
12 Screws
Table 6. FIADAST006* Y/D models (digit 39 = C)
Qty Description
1 Temperature sensing module
4 Sensing tubes
2 Mounting brackets
1 Pipe insulation
12 Screws
Table 7. FIADAST007/8* (digit 39 = D)
Qty Description
4 Sensing tubes
1
Temperature sensing module (including Sensor bracket, Harness assembly, Insulation, Wire ties, Sensor bracket screw, and Cap to
sensing tube screw connection)
1 Mounting bracket
4 Screws for mounting bracket to fan wall
3 Screws for sampling tube connections
Table 8. FIADAST009* Y/D models (digit 39 = B)
Qty Description
1 Temperature sensing module
5 Sensing tubes (extra tubes included)
2 Mounting brackets
1 Air blockoff bracket
1 Pipe insulation
13 10-16 UNC × 1/2-in. Screws
2 Wire cable ties - screw -in
