Table 9. Cooling Coil Weight Adder (Approximate)
Capacity
DX COIL
4 Row 6 Row
10, 15
70 lbs. 95 lbs.
20, 25, 50
95 lbs. 130 lbs.
30, 35, 60, 70
119 lbs. 166 lbs.
40, 80
130 lbs. 182 lbs.
Capacity
CHILLED WATER COIL
4 Row 6 Row
10, 15
170 lbs. 222 lbs.
20, 25, 50
215 lbs. 287 lbs.
30, 35, 60, 70
264 lbs. 359 lbs.
40, 80
284 lbs. 389 lbs.
Table 10. VFD Enclosure Weight Adder
Small Enclosure, VFD 1–5 HP
95 lbs.
Large Enclosure, VFD 7.5–15 HP
135 lbs.
Table 11. Indoor Arrangement “B, D, G, K” Shipping Weights (lbs.)
Capacity
Arrangement
B D G K
10 637 803 929
15 662 828 954
20 785 982 972 1103
25 812 1009 1021 1149
30 937 1163 1186 1321
30 983 1209 1238 1374
40 1048 1287 1314 1460
50 1144 1340 1349 1476
60 1318 1543 1565 1701
70 1389 1613 1634 1770
80 1490 1729 1748 1893
12 2181
UUnniitt SShhiippppiinngg WWeeiigghhttss
