Unit Clearances, Curb Dimensions, and Dimensional Data
OAU-SVX007A-EN 33
Notes:
• Certain options require auxiliary cabinet. Refer to project-
specific unit submittals.
• Sound attenuation package will add 17.76 in. to the height
of the condenser fan section. Refer to project-specific unit
submittals.
Indirect-Fired OAG Units
Unit Clearances
Figure 39. Unit dimensional data for OAB 3–9 tons with
auxiliary cabinet (in.)
)52179,(:
(/(&75,&
',6&211(&7
5,*+76,'(9,(:
5$
6$
%277209,(:
7+528*+%$6(
(/(&75,&
Figure 40. Typical installation clearances for indirect-
fired OAG unit
KCC
International Inc.
72"
84"
36"
KCC
International Inc.
36"
48"
36"
