Trane IntelliPak SFHK Series User Manual

72 RT-SVX36G-EN
Installation
Table 22. Electrical service sizing data — motors — 20-130 tons
Nominal
Tons
Nominal Voltage
200
FLA
230
FLA
460
FLA
575
FLA
Air-Cooled Condenser Fan Motor
20 8.2 8.2 3.6 2.8
25 12.3 12.3 5.4 4.2
30 12.3 12.3 5.4 4.2
40 16.4 16.4 7.2 5.6
50, 55 24.6 24.6 10.8 8.4
60 24.6 24.6 10.8 8.4
70 24.6 24.6 10.8 8.4
75 24.6 24.6 10.8 8.4
90 N/A N/A 14.4 11.2
105 N/A N/A 18.0 14.0
115 N/A N/A 18.0 14.0
130 N/A N/A 21.6 16.8
Motor Horsepower Supply/Exhaust/Return
2
Fan Motor
3 11.0 8.6 4.3 3.8
5 15.2 13.2 6.6 5.4
7½ 21.5 18.8 9.4 7.5
10 29.0 25.2 12.6 10.1
15 40.7 37.8 18.9 15.1
20 56.1 49.4 24.7 19.6
25 70.5 62.0 31.0 24.5
30 85.5 73.2 36.6 29.2
40
(a)
(a)40 Hp motor available as standard in 460 & 575 volt only.
N/A N/A 47.6 39.0
Note: Return fan motors are available in 3-20 Hp.
