Trane MCC Series Installation Manual

10
MCC-SVN01A-EN
Model MCC518AB MCC524AB MCC530AB MCC536AB
A. Height above ceiling 290 mm. 290 mm. 340 mm. 340 mm.
B. Height above suspension brackets 180 mm. 180 mm. 230 mm. 230 mm.
C. Height of condensate drain above ceiling 230 mm. 230 mm. 280 mm. 280 mm.
D. Pipe exit position 165 mm. 165 mm. 215 mm. 215 mm.
950
390
340
512
330
370350
THE CEILING HOLE 860~890
418
785
drainpipe outlet
830
60
main cable entry
B
C
D
22
refrigerant pipe
Dimensional Data
A
