Trane RT-PRC007-EN - Integrated Comfort System Sensors

39RT-PRC007-EN
Dimensional (CV and VAV)
Data
Note:
1. Remote sensors are available for use with all zone sensors to provide remote sensing capabilities.
REMOTE MINIMUM POSITION POTENTIOMETER CONTROL (BAYSTAT023*)
TEMPERATURE SENSOR (BAYSENS016*)
ZONE TEMPERATURE SENSOR W/TIMED OVERRIDE BUTTON
AND LOCAL SETPOINT ADJUSTMENT (BAYSENS014)
1
ZONE TEMPERATURE SENSOR W/TIMED OVERRIDE BUTTONS
(BAYSENS013*) ALSO AVAILABLE SENSOR ONLY (BAYSENS017*)
Integrated Comfort™ System Sensors
