Trane S8X1A040M3PSAA - Page 37

18-CE04D1-1B-EN
37
Table 7. Return Duct Connections (continued)
Downflow Furnace with Top Return and Plenum with Filter Box
1. Remove the top plate.
2. Attach the filter box to the top of the furnace.
3. Attach ducting.
4. Seal per local codes and requirements.
FILTER
FFuurrnnaaccee GGeenneerraall IInnssttaallllaattiioonn
