Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating,
ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly
installed, adjusted or altered equipment by an unqualified person could results in death of serious injury. When working
on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are attached to the
equipment.
Introduction
The Trane touch screen wall sensor THP05 is easily installed and configured with multiple options.
It is designed to communicate via Modbus with HVAC Airfinity rooftop unit equipped with controller module
CH536.
Keep this user guide in an accessible area for reference. Read this manual thoroughly before operating or
servicing this unit.
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as required. Your personal safety and the proper operation of
this machine depend upon the strict observance of these precautions.
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation which, if not avoided, could result in minor or moderate
injury. It could also be used to alert against unsafe practices.
NOTICE Indicates a situation that could result in equipment or property-damage only accidents.
Take Precautions During Installation!
If replacing an existing sensor, label the wires before removal. Electronic controls are static-sensitive devices.
Properly discharge yourself before manipulating and installing the sensor.
All sensors are designed for use as operating units only and are not safety devices.
Tampering with the device or unintended application of the device will void the warranty.
Copyright
This document and the information in it are the property of Trane and may not be used or reproduced in whole or
in part, without the written permission of Trane. Trane reserves the right to revise this publication at any time and
to make changes to its content without obligation to notify any person of such revision or change.
