Trane TUD1B080A9H31B User Manual

Installer’s Guide
18-CD21D1-12
From Dwg. 21C341699 Sh. 1 Rev. 4
*UD1-H OUTLINE DRAWING
(ALL DIMENSIONS ARE IN INCHES)
MODEL DIM "A" DIM "B" DIM "C" DIM "D"
TUD1A040A9H21B, TUD1A040G9H21A 14-1/2" 9-5/8" 13-1/4" 13" TUD1B060A9H31B, TUD1B060G9H31A TUD1B080A9H31B, TUD1B080G9H31A TUD1B100A9H31B, TUD1B100G9H31A
17-1/2" 9-5/8" 16-1/4" 16"
TUD1C080A9H41B, TUD1C080G9H41A TUD1C100A9H51B, TUD1C100G9H51A
21" 13-1/16" 19-3/4" 19-1/2"
TUD1D120A9H51B, TUD1D120G9H51A TUD1D140A9H51B, TUD1D140G9H51A
24-1/2" 15-5/16" 23-1/4" 23"
