Trane TurboTorch - Plasma Cutting Systems

RSP-PRC023-EN22
Plasma Cutting Systems
TOL02003
TPC-18
1/8 in. Cutting System (1445-0900)
Specifications
Output: 12 A fixed
Input: 120 V (+/-10%)
1 ph, 60 Hz, 20 A
Cut Capacity: 1/8 in. (3.2 mm)
Duty Cycle: 30%
Panel Controls: On/off lighted
Dimensions: Height: 10 in. (254 mm)
Width: 9 in. (229 mm)
Length: 16 in. (406 mm)
Weight: 63 lb (25 kg)
Gas: Air from built-in air compressor
Pilot: Electrode to tip
Control: Torch-mounted switch
Lead Length: 20 ft (6.1 m)
Torch Consumables Ordering Information
ServiceFirst Item No. Mfg. No. Part No. Description
TOL02010 TSC-25 1445-0903 Shield Cup for TPC-18 and TPC-25 (1pk)
TID00141 T-Tip-18 1445-0909 Cutting tip for TPC-18 Only (5pk)
DST00867 TGD-25 1445-0905 Gas Distributor for TPC-18 and TPC-25 (1pk)
ELC00066 TE-25 1445-0904 Electrode for TPC-18 and TPC-25 (5pk)
1
TOL02010
2
TID00141
3
DST00867
4
ELC00066
