30
VAV-SVX08R-EN
Table 8. Series fan–powered units — lb/kg (continued)
Unit Size
Single Wall
Dual Wall
VSxF
Suppressor
VSCF VSEF
VSWF
VSCF VSEF
VSWF
1–Row 2–Row 1–Row 2–Row
1004SQ
91/41 120/54 103/47 107/49 115/52 144/65 127/58 131/59 16.5/7.5
1005SQ
92/42 121/55 104/47 108/49 116/53 145/66 128/58 132/60 16.5/7.5
1006SQ
104/47 135/61 119/54 124/56 133/60 164/74 148/67 153/69 22.5/10.2
1007SQ
117/53 148/67 132/60 137/62 146/66 177/80 161/73 166/75 22.5/10.2
1203SQ
82/37 111/50 94/43 98/44 106/48 135/61 118/54 122/55 16.5/7.5
1204SQ
92/42 121/55 104/47 108/49 116/53 145/66 128/58 132/60 16.5/7.5
1205SQ
94/43 123/56 106/48 110/50 118/54 147/67 130/59 134/61 16.5/7.5
1206SQ
105/48 136/62 120/54 125/57 134/61 165/75 149/68 154/70 22.5/10.2
1207SQ
118/54 149/68 133/60 138/63 147/67 178/81 162/73 167/76 22.5/10.2
1404SQ
93/42 122/55 105/48 109/49 117/53 146/66 129/59 133/60 16.5/7.5
1405SQ
96/44 125/57 108/49 112/51 120/54 149/68 132/60 136/62 16.5/7.5
1406SQ
106/48 137/62 121/55 126/57 135/61 166/75 150/68 155/70 22.5/10.2
1407SQ
119/54 150/68 134/61 139/63 148/67 179/81 163/74 168/76 22.5/10.2
1606SQ
107/49 138/63 122/55 127/58 136/62 167/76 151/68 156/71 22.5/10.2
1607SQ
120/54 151/68 135/61 140/64 149/68 180/82 164/74 169/77 22.5/10.2
Table 9. Low height parallel units — lb/kg
Unit Size
Single Wall
Dual Wall
LPxF
Attenuator
LPCF LPEF
LPWF
LPCF LPEF
LPWF
1–Row 2–Row 1–Row 2–Row
05DS02
90/41 109/49 97/44 99/45 114/51 132/60 120/54 122/55 14/6
05PS02
93/42 110/50 99/45 101/46 116/52 133/60 122/55 124/56 14/6
06DS02
90/41 108/49 96/43 96/43 113/51 131/59 119/54 121/55 14/6
06PS02
92/42 110/50 98/44 100/45 115/52 133/60 121/55 123/56 14/6
08DS02
91/41 109/49 97/44 99/45 114/51 132/60 120/54 122/55 14/6
08PS02
93/42 110/50 99/45 101/46 116/52 133/60 122/55 124/56 14/6
14RTDS02
109/49 121/55 109/49 111/50 132/60 144/65 132/60 134/61 14/6
14RTPS02
111/50 123/56 111/50 113/51 134/61 146/66 134/61 136/61 14/6
