DIMENSIONAL DATA
3
YCZ036,050,060F OUTLINE – BACK
MODEL
CORNER WEIGHT (LBS)
NET
UNIT
WEIGHT
(LBS)
AB C D E F G H J K L MN P
W1 W2 W3 W4
YCZ036F 161 106 104 157 528 64 36 29-3/16 18-9/16 11-1/16 6-9/16 11-1/8 17 18-1/2 25-1/2 17-1/2 10 3 8-3/4
YCZ050F 172 121 137 196 626
65-1/8 45 33-3/8 21-1/16 15-1/16 4-15/16 9-1/8 21-15/16
24 26-1/2
20 14 3-1/2 8-5/1
YCZ060F 195 129 132 199 656 22-3/4 25-1/2
