400X CompactFlash Card
Transcend Information Inc.
V1.0
26
 I/O Input (Read) Timing Specification
Cycle Time Mode:
250 ns 120 ns 100 ns 80 ns
Item Symbol
IEEE
Symbol
Min
ns.
Max
ns.
Min
ns.
Max
ns.
Min
ns.
Max
ns.
Min
ns.
Ma
x
ns.
Data Delay after HIOE td(HIOE) tlGLQV 100
50 50 45
Data Hold following HIOE th(HIOE) tlGHQX 0
5
5
5
HIOE Width Time tw(HIOE) tlGLIGH 165
70
65
55
Address Setup before HIOE tsuA(HIOE) tAVIGL 70
25
25
15
Address Hold following HIOE thA(HIOE) tlGHAX 20
10
10
10
CEx Setup before HIOE tsuCE(HIOE) tELIGL 5
5
5
5
CEx Hold following HIOE thCE(HIOE) tlGHEH 20
10
10
10
HREG Setup before HIOE tsuREG (HIOE) tRGLIGL 5
5
5
5
HREG Hold following HIOE thREG (HIOE) tlGHRGH 0
0
0
0
Wait Delay Falling from HIOE
2
tdWT(HIOE) tlGLWTL 35 35 35 Na
1
Data Delay from Wait Rising
2
td(IORDY) tWTHQV 0 0 0 Na
1
Wait Width Time
2
tw(IORDY) tWTLWTH
350
350
350
Na
1
