400X CompactFlash Card
Transcend Information Inc.
V1.0
27
 I/O Output (Write) Timing Specification
Cycle Time Mode:
255 ns 120 ns 100 ns 80 ns
Item Symbol
IEEE
Symbol
Min
ns.
Max
ns.
Min
ns.
Max
ns.
Min
ns.
Max
ns.
Min
ns.
Ma
x
ns.
Data Setup before HIOW tsu(HIOW) tDVIWH 60
20
20
15
Data Hold following HIOW th(HIOW) tlWHDX 30
10
5
5
HIOW Width Time tw(HIOW) tlWLIWH 165
70
65
55
Address Setup before HIOW tsuA(HIOW) tAVIWL 70
25
25
15
Address Hold following HIOW thA(HIOW) tlWHAX 20
20
10
10
CEx Setup before HIOW tsuCE (HIOW) tELIWL 5
5
5
5
CEx Hold following HIOW thCE (HIOW) tlWHEH 20
20
10
10
HREG Setup before HIOW tsuREG (HIOW) tRGLIWL
5
5
5
5
HREG Hold following HIOW thREG (HIOW) tlWHRGH
0
0
0
0
Wait Delay Falling from HIOW
2
tdWT(HIOW) tlWLWTL
35
35 35 Na
1
HIOW high from Wait high
2
tdrHIOW (IORDY)
tWTJIWH
0
0
0
Na
1
Wait Width Time
2
tw(IORDY)
tWTLWT
H
350
350
350
Na
1
